Standard configuration

HFC R404a environmental friendly refrigerant;

Multi-function operating panel and uP controller;

Ultra-thin evaporator;

Hot gas defrosting system;

DC12V/24V operating voltage;

HFC134a or 452a refrigerant options may be available per prior agreement.

Safety devices
    • Emergency switch protection;
    • Thermal protection guard;
    • System HP/LP cutout switches;
    • System HP/LP cutout switches;
    • Wire harness ESD insulation methods which improve system protection from electromagnetic interference.
Operation and control component
Microprocessor control system;
Automatic / manual defrost;
Digital display
Fahrenheit or Celsius display for set point temperature and return air temperature, parameters setting alarm codes.
Product key features
01
Best choice for small reefer van;
02
Evaporator copper tubes with aluminum fins, fast cooling, large airflow;
03
Accurate temperature control, and perfect data monitoring on Fahrenheit or Celsius display;
04
Heating and electric stand-by options.
Specifications

Model

Refrigerant

Cooling Capacity(W)

Evaporator Airflow
(m3/h)

Application

(m3)

Evaporator

Condenser

Engine

Standby

Dimension
L*W*H(mm)

Weight(Kg)

Dimension
L*W*H(mm)

Weight(Kg)

0℃/+30℃

 -18℃/+30℃

0℃/+30℃

 -18℃/+30℃

KX-200R

R404a

2200

1127

1780

875

950

8~12

575*595*185

13

890*720*200

16

Note:
Application-internal volume is for reference only, it depends on insulation material (K factor should be equal or lower than 0.32Watts/m²℃), ambient temperature, precooling, load and type of goods etc.
