Standard configuration
HFC R404a environmental friendly refrigerant
Multi-function operating panel and uP controller
Hot gas defrosting system
DC12V/24V operating voltage
Safety devices
- Emergency switch protection
- Thermal protection guard
- System HP/LP cutout switches
- Wire harness ESD insulation methods for reducing electromagnetic interference
Operation and control component
-
Microprocessor control system -
Automatic/Manual defrost -
Digital display -
Fahrenheit or Celsius display for set point temperature and return air temperature, parameters setting alarm codes
Product key features
01
Streamlined appearance, beautiful and elegant
02
Internal ultra-thin evaporator, greatly increase the cargos loading capacity
03
Large cooling capacity ensure the goods safety even in high ambient temperature or frequent door opening
04
Large airflow volume, maintains the goods in good condition
05
Wide range of temperature control(-30℃~+30℃)
06
Microprocessor control, easy operation
07
Fast installation and convenient maintenance
08
Heating and electric stand-by options
Specifications
| Model | KX-180K | ||
| Cooling Capacity Ambient+30℃（86℉） |
Temperature | Watts | Btu/hr |
| 0℃/+32℉ | 2050 | 7505 | |
| -20℃/-4℉ | 1050 | 3845 | |
| Evaporator Airflow Volume | 900m³/h | ||
| Compressor |
Model | KX11 | |
| Displacement | 87cc | ||
| Condenser |
Fan motor quantity | 1pcs | |
| Dimension | 785*425*215mm | ||
| Weight | 19kg | ||
| Evaporator |
Fan motor quantity | 1pcs | |
| Dimension | 720*575*170mm | ||
| Weight | 13kg | ||
| Refrigerant Charge | R404a/1.0kg | ||
| Defrost | Hot gas defrost | ||
| Unit Operation Voltage | DC12V/DC24V | ||
| Application-box interal volume | 5m³（-20℃）~12m³（0℃） | ||
Note:
Application-internal volume is for reference only, it depends on insulation material (K≤0.32Watts/m²℃), ambient temperature, precooling, load and type of goods etc.
