Standard configuration
HFC R404a environmental friendly refrigerant;
Multi-function operating panel and uP controller;
Ultra-thin evaporator;
Hot gas defrosting system;
DC12V/24V operating voltage;
HFC134a or 452a refrigerant options may be available per prior agreement.
Specifications
| Model | KXE-805W | |||
| Cooling Capacity Ambient +30℃（86℉） | Temperature | Watts | Btu/hr | |
| 0℃/+32℉ | 7850 | 26785 | ||
| -20℃/-4℉ | 3480 | 11875 | ||
| Evaporator Airflow Volume | 2600m³/h | |||
| Condenser | Coil | Micro-channel | ||
| Fan motor quantity | 4pcs | |||
| Dimension | 2320*375*372mm | |||
| Weight | 140kg | |||
| Evaporator | Coil | Copper tube&aluminum fin | ||
| Fan motor quantity | 3pcs | |||
| Dimension | 1530*250mm | |||
| Rated Power | 5.5kW | |||
| Compressor | KX-43Q/43cc | |||
| Refrigerant Charge | R410a/3.7kg | |||
| Defrost | Hot gas defrost | |||
| Unit Operation Voltage | DC12V/DC24V | |||
| Vehicle VoltageD | DC350V~750V | |||
| Electric Standby&Heat | Optional | |||
| Application-box interal volume | 45m³（-20℃）~55m³（0℃） | |||
Note:
Application-internal volume is for reference only, it depends on insulation material (K factor should be equal or lower than 0.32Watts/m²℃), ambient temperature, precooling, load and type of goods etc.
