Standard configuration
HFC R404a environmental friendly refrigerant;
Multi-function operating panel and uP controller;
Hot gas defrosting system;
DC12V operating voltage;
HFC134a or 452a refrigerant options may be available per prior agreement.
Safety devices
- Emergency switch protection;
- Thermal protection guard;
- System high and low pressure cutout switches;
- Liquid injection and oil return protection ;
- Wire harness ESD insulation methods which improve system protection from electromagnetic interference.
Operation and control component
-
Microprocessor control system; -
Automatic / manual defrost; -
Digital display -
Fahrenheit or Celsius display for set point temperature and return air temperature, parameters setting alarm codes.
Product key features
01
Best choice for large refrigerated cargo trucks;
02
Driven by Japan built, highly reliable Shibaura Perkins 3 cylinder engine, long life; low running noise; low fuel consumption;
03
Stand-by motor uses aluminum shell, excellent heat exchange, high efficiency, stable performance;
04
Connection tubing between evaporator and condenser is very short, easy installation and reduced leakage possibility;
05
Axial fans, large air volume, long life;
06
Internally grooved copper tubing, high efficiency heat exchange for fast cooling;
07
Complete control system, pre-trip test, accurate temperature control, engine start or stop according to the set temperature;
08
Engine with two start ways and perfect data monitoring to ensure the equipment normal working;
09
When plugged on stand-by working mode, the unit will switch over from engine mode to electric motor automatically, thereby reducing fuel consumption and lower noise levels;
10
Meanwhile the unit will convert automatically to engine working mode in the event of the stand-by power failure, thereby keeping the cargo protected;
11
Optional data recorder, GPS and remote control functions.
Specifications
|
Model |
Refrigerant |
Weight(Kg) |
Dimension |
Cooling capacity(W) |
Evaporator airflow |
Application- (m3) |
Evaporator opening size |
|||
|
Road |
Standby |
|||||||||
|
0℃/+30℃ |
-18℃/+30℃ |
0℃/+30℃ |
-18℃/+30℃ |
|||||||
|
KSD-600 |
R404a |
395 |
1795*795*560 |
5760 |
3350 |
4930 | 2935 |
2350 |
15~30 |
1245*310 |
Note:
1.Internal volume is for reference only, it depends on insulation material (K factor should be equal or lower than 0.32Watts/m²℃), ambient temperature, precooling , load and type of goods etc.
2.All datum and specifications may change without notice.
