Standard configuration
HFC R404a environmental friendly refrigerant;
Multi-function operating panel and uP controller;
Hot gas defrosting system;
DC12V operating voltage;
Safety devices
- Emergency switch protection;
- Thermal protection guard;
- System HP/LP cutout switches;
- Wire harness ESD insulation methods which improve system protection from electromagnetic interference.
Operation and control component
-
Microprocessor control system; -
Automatic / manual defrost; -
Digital display -
Fahrenheit or Celsius display for set point temperature and return air temperature, parameters setting alarm codes.
Product key features
01
Driven by Japan built, highly reliable Shibaura Perkins 3 cylinders engine, low running noise and fuel consumption;
02
Stand-by motor uses aluminum shell, excellent heat exchange, high efficiency, stable performance;
03
Connection tubing between evaporator and condenser is very short, reduced leakage possibility;
04
Axial fans, large air volume, long life;
05
Internally grooved copper tubing, high efficiency heat exchange for fast cooling;
06
Complete control system, pre-trip test, accurate temperature control, engine start or stop according to the set temperature;
07
Automatically switched between engine and standby work, reducing fuel consumption and lower noise levels;
08
Optional data recorder, GPS and remote control functions.
Specifications
| Model | Return Air Temperature | Engine | Electric Standby | Airflow Volume | Weight | Evaporator Opening | Refrigerant Charge | |
| KSD-1200 | 0℃/32℉ | Watts | 10825 | 9350 | 2580m³/h | 560kg | 1245*350mm | R404A/6.3KG |
| Btu/hr | 36935 | 31900 | ||||||
| -20℃/-4℉ | Watts | 5555 | 5170 | |||||
| Btu/hr | 18955 | 17630 | ||||||
Note:
Application-box internal volume is for reference only, it depends on insulation material (K factor should be equal or lower than 0.32Watts/m²℃), ambient temperature, precooling, load and type of goods etc.
